CWDM SFP 10G

CWDM SFP 10G transceiver is designed for 10G Ethernet (10GBASE-ER/EW) and 10G Fiber Channel.

This module is designed for single mode fiber and operates at CWDM wavelength. There are four center wavelengths available from 1270nm to 1330nm, with each step 20nm. A guaranteed minimum optical link budget of 14 dB is offered.

 Features:

• Supports 9.95Gb/s to 11.1Gb/s Bit Rates
• Hot-Pluggable SFP+ Footprint
• 4-Wavelengths CWDM DFB Transmitter, 1270nm, 1290nm, 1310nm, 1330nm
• 14dB Power Budget at Least
• Duplex LC connector
• Case Operation Temperature Range 0°C  to  70°C
• Compliant with SFP+ MSA Specification SFF-8431
• Build-in Digital Diagnostic Functions
• Digital Diagnostic Monitor Interface Compliant with SFF-8472 MSA Specification


Applications

• 10GBASE-ER/EW 10G Ethernet
• 1200-SM-LL-L 10G Fiber Channel
• ITU-T G.709

• Programmed for : HP, Cisco and others
